КорзинаШатунные вкладыши ACL 4B8296HX-STD-STD для Subaru EJ20/EJ22/EJ25 (incl. Turbo) c 98г.в. 52 mm
 увеличить... |
| ||||||||||||
| ENGINE BEARINGS | ||||
 | CON ROD BEARING SET | MAIN BEARING SET | ||
| Part# | Part# | |||
| 4B8296H | 4B8296HX | 5M8297H | 5M8297HX | |
| Sizes | STD, .025, .25, 0.5 | STD | STD, .025, .25, 0.5 | STD |
| Oil Clearance | Standard | + 0.001" Extra | Standard | + 0.001" Extra |
| Half Type | Identical Halves | Identical Halves | ||
| Material | Tri-metal Hardened steel backs | Tri-Metal | ||
| Min Std Shaft Size | 2.0466in / 51.984mm | 2.3616in / 59.984mm | ||
| Max Std Shaft Size | 2.0472in / 52.000mm | 2.3622in / 60.000mm | ||
| Min Std Tunnel Size | 2.1654in / 55.000mm | 2.5197in / 64.000mm | ||
| Max Std Tunnel Size | 2.1661in / 55.020mm | 2.5205in / 64.020mm | ||
| Max Wall at Crown | 0.0591in / 1.500mm | 0.0585in / 1.487mm | 0.0789in / 2.005mm | 0.0784in / 1.992mm |
| Max Overall Length | 0.6496in / 16.50mm | 0.7480in / 19.00mm (8297H/HX) 0.5953in / 15.12mm (8298H/HX) 0.8642in / 21.95mm (8299H/HX - Flange) | ||
| Notes | Suits 52mm journal only | Thrust in #3 pos. | ||
Diagram |  | 8297H & HX - Positions 1, 5
8298H & HX - Positions 2, 4
8299H & HX - Position 3
| ||
